Bosch HUI30253UC 300 Series Custom insert 30 inch

Product Description

The Bosch HUI30253UC 300 Series custom insert is designed to blend seamlessly with custom cabinetry for a premium kitchen aesthetic. This 30-inch hood insert features multiple speed settings to remove odors quickly and effectively. It comes with dishwasher-safe filters for convenient cleanup and a 300 CFM integral blower.

• Filters that are Dishwasher Safe
• Hoods with smart connectivity make life easier.
• Dishwasher safe mesh filters makes cleaning and maintenance easy.

Product Highlights

This Bosch hood insert offers convenience and performance, ensuring a fresh and modern kitchen environment.

Product Information

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: HUI30253UC

Technical Specifications

• Installation Type: Built-in
• Venting: Exhaust / Recirculation (Accessory available separately)
• Material Number: HUI30253UC
• Brand Name: Bosch
• Category: Undercabinet Range Hoods
• Product Name: 300 Series, canopy cooker hood, Stainless steel
• Upc: 825225961024
• Series: 300 Series
• Appliance Color/Finish: Stainless Steel
• Ada Compliant: No
• Wattage: 157
• Connection Rating (W): 157
• Voltage: 120 Volts
• Frequency: 60 Hz
• Clean Filter Reminders: No
• Basic Touch Control: No
• Color Temperature: Cold white (4.000 K)
• Grease Filter Type: Kassette
• Heat Lamps: No
• Light Control Type: Continuous
• Number Of Speed Settings: 3-stages + intensive setting
• Operating Mode: Convertible: Ducted / Recirculating
• Total Luminance (Lm): 150
• Touch Slider: No
• Type Of Control: Electronic
• Extremely Quiet - Ecosilence Drive: No
• Light Type: Halogen
• Number Of Lights: 2
• Type Of Lamps Used: Low consumption
• Connected Appliances With Home Connect: Yes
• Home Connect Features: Remote Monitoring and Control
• Damper Included: Yes
• Power Cord Length: 51"
• Plug Type: 120V-3 Prong
• Required Distance Above Cooktop/Ranges: 30/30
• CFM: 300 CFM
• Venting Type: Convertible
• Style: Standard Hood
• Width: 26 1/2"
• Height: 10 1/2"
• Depth: 10 5/8"
• Motor Location: Integrated Motor in Hood Body
• Maximum CFM: 300
• Light Lumens: 100 - 150
• Grease Filter Material: Aluminum Dishwasher Safe
• Bulb Type: LED
• Total Power of The Lamps (W): 6 W
• Wi-Fi Enabled: Yes
• Volts: 120V
• CEE Rating: Not Available
• Approved for Outdoor Use: No
• Energy Star Rated: No
• Type: Cabinet Insert
• Blower Type: Internal
• Blower Included: Yes
• Mounting Type: Under Cabinet
• Glass Canopy: No
• Required Distance Above Cooktop/Range Cooking Surface: 24" Electric / 30" Gas
• Diameter of Air Duct: 6"
• Duct Size: 6 Inch
• Model: HUI30253UC
• Dishwasher Safe Filters: Yes
• Number of Fan Speeds: 4
• Lights: LED
• Lighting Levels: 2
• Filter Type: Mesh
• Manufacturer: Bosch
• Product group: Hood
• SKU: HUI30253UC
• Internal article number: HUI30253UC
• EAN code: 4242005202997
• Color body: Stainless Steel
• Material: Stainless Steel
• Typology: Built-in/Built-under
• Type of control: Touch Control;Via app
• Construction type: Built-in
• Motor location: Integrated motor in hood body
• Watts (W): 157
• Air exhaust: Yes
• Diameter of air duct top: 6
• Overall appliance dimensions (HxWxD): 12 3/4'' x 26 1/2'' x 10 5/8''
• Discharge direction: vertical
• Total annual energy consumption: 52.0
• Type of manual control devices: touch control
• Remote control: No
• Total output power of the motors: 150
• Total power of the lamps (W): 40
• Total luminance (lux): 150
• Diameter of air duct (mm): 150
• No-return airflow flap: No
• Odour filter: No
• Net weight: 23.000
• Gross weight: 27.000
