Bosch 8733980457 Single Zone Mini Split Kit 9000 Btu/h

Product Description

The BOSCH 8733980457 is a single-zone ductless mini split heat pump kit rated at 9000 BTU/h for residential and light-commercial zoning applications. The system ships as a matched set, including one indoor unit (IDU) and one outdoor unit (ODU), pre-validated for AHRI-certified performance at 26.0 SEER2, 14.9 EER2, and 12.5 HSPF2. Operating on 230-volt power, this kit carries an Energy Star certification and delivers a COP of 4.6 at 47 degrees F, making it well-suited for heating-dominant climates. Licensed HVAC technicians install this system as a complete matched assembly.

This kit is designed for single-zone ductless installations in residential spaces such as bedrooms, additions, sunrooms, and open-plan areas, as well as small commercial offices or server rooms. The 9000 BTU/h capacity fits spaces where a single indoor head provides sufficient conditioning. Both the indoor and outdoor units arrive together as a factory-matched pair, reducing the risk of mismatched component selection on the job site. This kit does not include a line set.

Key Features

• AHRI-certified 26.0 SEER2 efficiency rating
• 14.9 EER2 and 12.5 HSPF2 for balanced cooling and heating performance
• COP of 4.6 at 47 degrees F for effective cold-climate heating
• Energy Star certified
• Factory-matched indoor and outdoor unit pair included in one kit
• 230-volt operation compatible with standard residential electrical service

Compatibility

This kit includes IDU component 8733962676 and ODU component 8733962684, supplied as a matched pair. Designed as a factory-matched single-zone ductless mini split replacement or new-installation kit for 230-volt residential and light-commercial applications.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA 608 certification for refrigerant handling. Disconnect and lock out all electrical power before servicing or connecting any components. Line set, disconnect, and interconnecting wiring are not included and must be sourced separately per NEC requirements. Follow the manufacturer installation manual for refrigerant line sizing, flaring procedures, and indoor unit mounting height to ensure rated system performance.

Technical Specifications

• Capacity: 9000 BTU/h
• SEER2: 26.0
• EER2: 14.9
• HSPF2: 12.5
• COP at 47 degrees F: 4.6
• Voltage: 230V
• Energy Star: Yes
• Kit Net Weight: 85.54 pounds
• Kit Gross Weight: 132.66 pounds
• UPC: 52575023571

Standard Information

• Brand: BOSCH
• Manufacturer Part Number: 8733980457
