Bosch 8733952994 Connected Control BCC50 Thermostat

Product Description

The Bosch Connected Control BCC50 is a digital, programmable thermostat with a compact and efficient design that suits hardwired installation. It operates on a twenty-four VAC electrical rating and supports up to two stages of cooling and three stages of heating. This thermostat has terminal designations for G, Y, Y2, W/E/AUX, O/B/W2, and H/DH.

• Digital and programmable features enhance temperature control.
• Hardwired operation provides stability and reliable performance.
• Compatibility with multiple heating and cooling stages increases versatility.

Product Highlights

This model delivers advanced programming options for efficient energy management.

Product Information

Standard Information

• Brand: Bosch
• MPN: 8733952994

Technical Specifications

• Power Method: Hardwired
• Voltage: 24 VAC
• Electrical Rating: 24 VAC (18-30 VAC), 1 amp maximum per output terminal, 6 amp maximum total load
• Stages Cool: 2
• Stages Heat: 3
• Terminal Designations: G, Y, Y2, W/E/AUX, O/B/W2, H/DH
