BOSCH 5261234 Hydraulic Directional Valve

Product Description

The BOSCH 5261234 is a screw-in, cartridge-style hydraulic directional valve. This valve is designed for controlling fluid flow in hydraulic systems. In its neutral position, the valve permits bidirectional flow from port three to port two while blocking port four. When a remote pilot signal is received at port one, the valve's spool shifts to enable flow between port three and port four while blocking port two.

• Screw-in, cartridge-style design
• Pilot-operated, spool type valve
• Industry-common cavity design

Product Highlights

This valve is ideal for various hydraulic applications, featuring a compact size and reliable operation.

Product Information

Standard Information

• Operating Fluid Temperature: -40 to 100 °C (-40 to 212 °F) with buna N seals
• Pressure Rating: 241 bar (3500 psi)

Technical Specifications

• Flow Rating: See performance graph
• Storage Temperature: -40 to 70 °C (-40 to 160 °F)
• Ambient Temperature: -40 to 90 °C (-40 to 194 °F)
• Fluids: Mineral based or synthetic hydraulic fluid with lubricating properties
• Fluid Viscosity Range: 7.4 to 420 cSt
• Maximum Operating Contamination Level: 18/16/13 per ISO 4406
• Cavity: VC10-4
• Cartridge Installation Torque: 32.6 to 35.4 N-m (24 to 26 ft-lb)
