Bohn BEL0100BS6EEAB0400 Evaporator Low Profile 1-Speed EC 208-230/1/60

Product Description

The Bohn BEL0100BS6EEAB0400 is a low-profile evaporator designed for efficient cooling performance. This unit is ideal for trade professionals seeking reliable refrigeration solutions.

• Internally enhanced tubing for efficiency
• Quick-removal fan guard for easy servicing
• Factory-installed liquid line solenoid wire harness

Product Highlights

This evaporator features a molded fan guard and access panels, ensuring durability and ease of maintenance. It includes a hot gas loop on the bottom of the coil, adjustable defrost termination, and an intelliGen Refrigeration Controller for advanced control and monitoring.

Product Information

Standard Information

• Brand: Bohn
• Model: BEL0100BS6EEAB0400

Technical Specifications

• Voltage: 208-230 VAC
• Amps: 1
• Phase: Single
• Width: 13.25 inches
• Height: 16.4375 inches
• Length: 45.5 inches
• Weight: 59 lbs
• UL Listed: No
• ETL Listed: No
• Motor Type: ECM (Electronically Commutated Motor)
• Cycle/Hertz: 60 Hz
• Refrigerant: R-404A; R-407A; R-407C; R-448A; R-449A; R-407F
• Unit Cooler Type: Walk-In
• Energy Star Rated: No
• Fins per Inch (FPI): 6
• Drain Connection Size: 3/4 inch
• Liquid Line Size (OD): 1/2 inch
• Suction Line Size (OD): 7/8 inch
• Unit Cooler Nominal BTU: 10,000
• Unit Cooler Defrost Type: Electric
• Unit Cooler Number of Fans: 2
• Unit Cooler Evaporator Style: Low Profile
• Minimum Circuit Ampacity (MCA): 1.1
• Country of Origin: USA
• Prop 65: Yes
