Blackburn IPC1102 CONNECTOR PIERCING INSULATION 8 TO 2 AWG

Product Description

The Blackburn IPC1102 is an insulation piercing connector designed for use with aluminum or copper conductors ranging from eight to two AWG. This connector provides a reliable solution for splicing or tapping without the need for stripping insulation. It is rated for 600 VAC and is suitable for both non-tension and hot line applications.

• Accommodates conductor sizes from eight to two AWG.
• Self-insulated, eliminating the need for taping after installation.
• Designed for use on insulated conductors only.

Product Highlights

The IPC1102 combines ease of use with effective performance, allowing for fast installations while maintaining electrical safety.

Product Information

Standard Information

• Brand: Blackburn
• Manufacturer: ABB - Installation Products

Technical Specifications

• MPN: IPC1102
• Conductor Size: 8 to 2 AWG
• Voltage Rating: 600 VAC
• Temperature Rating: 90 deg C
• Finish: TiN Coated
• Dimensions: 1-17/32 inches L x 2-29/16 inches W
• Mounting Holes: 1
• Weight: 26 lbs
