Bk 496-062 Faucet Connector 1/2 in Fip X 1/2 in Comp 16 in

Product Description

The BK 496-062 is a braided stainless steel faucet supply connector designed for water supply connections to plumbing fixtures. It features a 1/2-inch female iron pipe (FIP) inlet and a 1/2-inch compression outlet on a 16-inch length. The inner core is virgin PVC reinforced with polyester yarn braiding, then over-braided with 304 stainless steel for burst resistance. Chrome-plated brass hex nuts and included washers provide a dependable hand-tight seal without the need for tools at the connection point. Rated to a maximum of 180 degrees F and 125 psi, this connector meets the demands of residential, commercial, and industrial water supply applications.

This connector is used to link shut-off valves to faucets, toilets, and other plumbing fixtures in kitchens, bathrooms, laundry rooms, and light commercial settings. The 16-inch length accommodates standard under-sink rough-in configurations. Its approval for residential, commercial, and industrial water supply applications makes it a versatile stock item for service plumbers and remodeling contractors working across multiple job types.

Key Features

• 304 stainless steel over-braid provides corrosion resistance and mechanical strength
• Virgin PVC core with polyester yarn reinforcement resists pressure surges
• Chrome-plated brass hex nuts rated for hand-tight, leak-free sealing
• Rated to 125 psi maximum working pressure
• Maximum temperature rating of 180 degrees F
• IAPMO listed for residential, commercial, and industrial water supply use

Compatibility

Designed as an OEM-style replacement or new-installation supply line for standard faucets, toilets, and plumbing fixtures requiring a 1/2-inch FIP inlet and 1/2-inch compression outlet connection.

Installation Notes

Installation is performed by a licensed plumber or qualified tradesperson. Shut off the water supply and relieve line pressure before disconnecting any existing supply line. Hand-tighten the brass nuts and verify alignment before applying any additional turns to avoid cross-threading. Follow local plumbing codes and IPC requirements for supply line materials and pressure ratings in your jurisdiction.

Technical Specifications

• Inlet Connection: 1/2 inch Female Iron Pipe (FIP)
• Outlet Connection: 1/2 inch Compression
• Length: 16 inches
• Maximum Pressure: 125 psi
• Maximum Temperature: 180 degrees F
• Core Material: Virgin PVC with polyester yarn braiding
• Outer Braid Material: 304 Stainless Steel
• Nut Material: Chrome-plated Brass
• Certification: IAPMO Listed
• Weight: 0.259 pounds

Standard Information

• Brand: BK
• Manufacturer Part Number: 496-062
