Best 711127400 Extra Heavy Full Surface Hinge 2in Steel

Product Description

The BEST 711127400 is an extra heavy full surface hinge designed for demanding door applications where both hinge leaves mount directly onto the face of the door and frame rather than mortised into them. Built from steel with a plain finish, it measures 2 inches in overall height and 2 inches in overall width, with each leaf measuring 1 inch wide and 2 inches tall. The leaf thickness is 0.099 inches and the non-removable pin measures 0.204 inches in diameter. This hinge is installed by commercial door hardware technicians and finish carpenters working on heavy-duty door assemblies requiring surface-mounted hardware.

This hinge suits full surface mount applications where mortising is not practical or desired, such as on metal doors, hollow metal frames, or retrofit installations on existing doors. The extra heavy construction makes it appropriate for high-cycle or high-traffic door environments. The plain steel finish accepts field-applied paint or coatings as needed for the installation. The nominal size is 2 inches by 2 inches, making it suitable for lighter door panels or small access doors requiring a compact, robust hinge.

Key Features

• Full surface mount — no mortising required on door or frame
• Extra heavy hinge type rated for demanding, high-cycle applications
• Non-removable pin for added security
• Steel construction with plain finish ready for field coating
• Compact 2 inches by 2 inches nominal size for smaller door panels and access doors
• Leaf thickness of 0.099 inches with a 0.204-inch pin diameter for solid pivot performance

Compatibility

Designed as an OEM-style full surface replacement hinge for steel doors, hollow metal frames, and access panels requiring a 2-inch by 2-inch surface-mount hinge with a non-removable pin.

Installation Notes

Installation is typically performed by a commercial door hardware technician or licensed contractor. Power down any electrified door hardware and ensure the door is properly supported before removing existing hinges. Fastener selection should match the door and frame substrate material. Follow applicable building codes and manufacturer fastener requirements for the door weight and frequency of use.
