BELL & GOSSETT P75396 Mechanical Seal Assembly

Product Description

The BELL & GOSSETT P75396 Mechanical Seal Assembly fits BELL & GOSSETT pumps from ITT CORP. It is essential for glycol service applications and accommodates a shaft diameter of two point one two five inches.

• Compatible with BELL & GOSSETT pumps
• Designed for glycol service
• Made from Ethylene Propylene Rubber (EPR)

Product Highlights

This mechanical seal assembly includes a PS-3020 seal part number and features a G Head type with an outer diameter of two point seven one seven inches. It has a ceramic seat material and is an O-Ring Mount type. The seat outer diameter is three inches with a thickness of zero point five six two inches.

Product Information

Standard Information

• Manufacturer Part Number: P75396
• Seal Part Number: PS-3020

Technical Specifications

• Material Code: QCFJF
• Shaft Diameter: two point one two five inches
• Service Application: Glycol
• Head Elastomer: Ethylene Propylene
• Washer Material: Carbon
• Head Type: G Head
• Head Outer Diameter: two point seven one seven inches
• Operating Height: one point one eight one inches
• Seat Type: O-Ring Mount
• Seat Material: Ceramic
• Seat Outer Diameter: three inches
• Seat Thickness: zero point five six two inches
• Material: Ethylene Propylene Rubber (EPR)
• Weight: 25 lbs
