Belimo ZONE225N-80+ZONE24NO Zone Valve 24V

Product Description

The BELIMO ZONE225N-80+ZONE24NO is a zone valve designed for HVAC applications. This 2-way valve features a 1" valve size and a CV of 8. It includes a spring return zone valve actuator and operates on 24VAC with an on/off input. It is suitable for use with chilled or hot water up to 50% glycol.

• Valve Size: 1"
• Control Type: On/Off
• Actuator Type: Spring return

Product Highlights

This Belimo zone valve is ideal for controlling water flow in HVAC systems, providing reliable on/off operation with its spring return actuator.

Product Information

Standard Information

• Brand: BELIMO
• Manufacturer Part Number: ZONE225N-80+ZONE24NO

Technical Specifications

• Angle of Rotation: 90
• Cv: 8
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 50% glycol
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Stainless steel
• Valve Size: 1" [25]
• Actuator Type: Spring return
• Control Type: On/Off
• Degree of Protection: IP20 NEMA 1
• Electrical Connection: cable
• Power Consumption (Running): 6.5 W
• Running Time (Fail-safe): <5 s
• Voltage AC/DC: AC24V
