Belimo EFX24-SR-S N4H Direct Coupled Actuator 270 in-lb

BELIMO
Brand: BELIMO
SKU: EFX24-SR-S N4H
Availability: Out Of Stock
$1,647.63
$1,647.63
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The BELIMO EFX24-SR-S N4H is a direct coupled actuator with 270 in-lb torque. It is designed for fail-safe, modulating control of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer’s specifications. It provides a feedback signal for position indication or master-slave applications.

  • Provides constant torque to the damper with, and without, power applied to the actuator
  • May be stalled anywhere in its normal rotation without the need of mechanical end switches
  • Provided with two built in auxiliary switches that provide safety interfacing or signaling

Product Highlights

This actuator offers reliable damper control with spring return functionality and versatile control options.

Product Information

Standard Information

  • Brand: BELIMO
  • Manufacturer Part Number: EFX24-SR-S N4H
  • Country of Origin: United States
Technical Specifications
Housing
IP66, NEMA 4X, UL Enclosure Type 4
Auxiliary Switch
2 x SPDT
Power Consumption
8 W Running, 4.5 W Holding
Operating Conditions
-22 F To 122 F (-30 C To 50 C)
Electrical Connection
Terminal Block(s) Inside Junction Box With Knockouts
Actuator Type
Spring return
Angle of Rotation
95
Control Type
DC 2...10 V
Degree of Protection
IP66 NEMA4 ULEnclosureType4
Direction of Rotation (Fail-Safe)
Reversible with cw/ccw mounting
Manual Override
5 mm hex crank (3/16" Allen) supplied
Power Consumption (Holding)
4.5 W
Power Consumption (Running)
8 W
Running Time (Fail-safe)
<20 s
Running Time (Motor)
95s / 90B0
Safety Function
YES
Torque
270 in-lb [30Nm]
Voltage AC/DC
AC/DC24V
Runtime
95 Secs
Voltage
24vdc
Nema Rating
Nema 4
Spring Return
Spring Return
Supply Va
14 VA
Supply Voltage (Nominal)
24 VAC
Control Signal
Analog
Input Impedance
SR Models: 100 k 4-20 mA; MFT Models: 100 k 4-20 mA; 1500
Motor
Brushless DC
Wiring
TFB, LF: 3' (0.9 m) cable, 18 AWG, plenum rated (modulating models) - 3' (0.9 m) appliance cable (on/off, MFT, -S models); NFB, AFB, EFB: 3' (0.9 m) appliance cable, 18 AWG; NEMA 4: Terminal blocks inside housing
Conduit Connection
w/Cables: 1/2" NPT; NEMA 4: Four knockouts for waterproof conduit fittings
Feedback
2-10 VDC (-SR and -MFT models only)
Spring Return Time
< 60 seconds
Rotation
95 < 71.4 db
Resolution
100 steps
Life Expectancy
2-Position: 60,000 cycles; Float/Prop.: 60,000 cycles; 500,000 repositions
Operating Temperature
-22 4 models with heater option can go down to -40
Operating Humidity
5 to 95% RH
Approvals
cULus, CE, RoHS
