Belimo B253+ARX24-SR-T N4 CCV Assembly 2 Way 120 Cv

Product Description

The Belimo B253+ARX24-SR-T N4 is a characterized control valve designed for effective temperature regulation. This model features a nickel-plated brass body and a stainless steel ball and stem, ensuring durability and reliability. It operates with a non-fail-safe, direct-coupled actuator that works with both AC and DC power.

• Functional control from 2 to 10 VDC or 4 to 20 mA signal.
• Adjustable flow for both chilled and hot water applications.
• Rated for NEMA 4X environments for enhanced protection.

Product Highlights

This valve supports various control signals while being suitable for medium temperature applications. It is ideal for HVAC systems requiring precise flow control.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B253+ARX24-SR-T N4

Technical Specifications

• Actuator Type: Non fail-safe
• Control Type: DC 2...10 V
• Cv: 120
• Valve Size: 2 inches
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Pressure Independent: No
• Degree of Protection: IP66/67 NEMA 4X
• Power Consumption (Running): 2.5 W
• Voltage AC/DC: 24 V
