Belimo B248+ARX24-SR-T N4 CCV Assembly, 2 Way, 2 in. NPT, 29 Cv

Product Description

The Belimo B248+ARX24-SR-T N4 is a characterized control valve designed for HVAC applications. This valve features a nickel-plated brass body and is equipped with a stainless steel ball and stem.

• Direct coupled actuator with non-fail safe operation
• Operates at 24 VAC/DC with modulating capabilities
• Compatible with 2 to 10 VDC or 4 to 20 mA control signals

Product Highlights

This valve is suitable for controlling chilled or hot water systems with glycol mixtures. It provides reliable flow control and integrates easily with various HVAC systems.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B248+ARX24-SR-T N4

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 degrees
• Cv: 29
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 2-way
• Pressure Independent: No
• Trim: Stainless steel
• Valve Size: 2 inches (50 mm)
• Actuator Type: Non fail-safe
• Control Type: DC 2...10 V
• Degree of Protection: IP66/67 NEMA 4X UL Enclosure Type 4X
• Electrical Connection: Terminals
• Manual Override: Under cover
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
• Running Time (Motor): 90 seconds / 90 degrees
• Voltage AC/DC: AC/DC 24 V
