Belden Inc. C632206020 Cat6 Plus Plenum Pigtail 20in

Product Description

The BELDEN INC. C632206020 is a Cat6 Plus plenum-rated pigtail patch cable finished in blue, designed for structured cabling installations in commercial and residential buildings. This single-ended pigtail style cable is used to terminate network runs at patch panels, keystone jacks, or structured media centers where a factory-terminated end is needed on one side. At 20 inches in length, it is suited for short-run connections inside enclosures or equipment racks. Plenum-rated construction means the cable jacket meets CMP fire and smoke standards required for installation in air-handling spaces. Licensed low-voltage cabling technicians and network installers are the primary trades who handle this type of cable.

This pigtail cable is used in Cat6 and Cat6 Plus structured cabling systems in commercial office builds, data closets, and residential network installations. The 20-inch length is typical for patch panel work inside shallow wall enclosures or short equipment-bay runs. The plenum rating makes it code-compliant for air-handling plenum spaces without the need for additional conduit in those areas. It ships as a single unit and is sold individually.

Key Features

• Cat6 Plus performance rating for gigabit and higher-speed Ethernet applications
• CMP plenum-rated jacket meets fire and smoke requirements for air-handling spaces
• Blue jacket color for easy visual identification and cable management
• Pigtail design provides one factory-terminated end for quick patch panel or jack termination
• 20-inch length optimized for short in-enclosure or rack runs

Compatibility

Designed as an OEM-style replacement or standard installation component for Cat6 and Cat6 Plus structured cabling patch panel systems in plenum-rated environments.

Installation Notes

Installation should be performed by a licensed low-voltage cabling technician in accordance with TIA-568 structured cabling standards and applicable local building codes. De-energize or power down any active equipment in the rack or enclosure before routing and terminating cables. Avoid sharp bends beyond the minimum bend radius of the cable, and do not crush or kink the jacket during routing. Plenum spaces require CMP-rated cabling per NFPA 90A — confirm the rating label on the cable before installation in any air-handling space.
