Baldor EM2547T 60 HP 1775 RPM 364T 4278M OPSB F1

Product Description

The BALDOR EM2547T is a 60 HP, 1775 RPM three-phase general purpose motor with a NEMA 364T frame and an Open Steel Band (OPSB) enclosure. Operating on 230/460V at 60 Hz, this motor features a 1.15 service factor and Class F insulation. It is foot mounted (F1) for applications like pumps, fans, and conveyors.

• NEMA Premium efficient motor
• Foot mounted (F1)
• Suitable for applications like pumps, fans, and conveyors

Product Highlights

60 HP, 1775 RPM motor with OPSB enclosure and 364T frame, suitable for industrial applications.

Product Information

Standard Information

• Brand: BALDOR
• Manufacturer Part Number: EM2547T
• Country of Origin: US

Technical Specifications

• Catalog Number: EM2547T
• Enclosure: OPSB
• Frame: 364T
• Frame Material: Steel
• Frequency: 60.00 Hz
• Motor Letter Type: Three Phase
• Output @ Frequency: 60.000 HP @ 60 HZ
• Phase: 3
• Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
• Voltage @ Frequency: 460.0 V @ 60 HZ 230.0 V @ 60 HZ
• Agency Approvals: CURUSEEV NEMA PREMIUM NEMA_PREMIUM
• Ambient Temperature: 40 C
• Auxiliary Box: NO AUXILLARY BOX
• Auxiliary Box Lead Termination: None
• Base Indicator: Rigid
• Bearing Grease Type: Polyrex EM (-20F +300F)
• Blower: None
• Current @ Voltage: 68.000 A @ 460.0 V 144.000 A @ 208.0 V 136.000 A @ 230.0 V
• Design Code: A
• Drip Cover: No Drip Cover
• Duty Rating: CONT
• Efficiency @ 100% Load: 95.0 %
• Electrically Isolated Bearing: Not Electrically Isolated
• Feedback Device: NO FEEDBACK
• High Voltage Full Load Amps: 68.0 a
• Front Face Code: Standard
• Front Shaft Indicator: None
• Heater Indicator: No Heater
• Insulation Class: F
• Inverter Code: Inverter Ready
• IP Rating: NONE
• KVA Code: G
• Lifting Lugs: Standard Lifting Lugs
• Locked Bearing Indicator: Locked Bearing
• Motor Lead Exit: Ko Box
• Motor Lead Termination: Flying Leads
• Motor Lead Quantity/Wire Size: 9 @ 6 AWG
• Motor Type: 4278M
• Mounting Arrangement: F1
• Number of Poles: 4
• Overall Length: 30.69 IN
• Power Factor: 87
• Product Family: General Purpose
• Pulley End Bearing Type: Ball
• Pulley Face Code: Standard
• Pulley Shaft Indicator: Standard
• Rodent Screen: None
• Service Factor: 1.15
• Shaft Diameter: 2.375 IN
• Shaft Extension Location: Pulley End
• Shaft Ground Indicator: No Shaft Grounding
• Shaft Rotation: Reversible
• Shaft Slinger Indicator: No Slinger
• Speed: 1775 rpm
• Speed Code: Single Speed
• Motor Standards: NEMA
• Starting Method: Direct on line
• Thermal Device - Bearing: None
• Thermal Device - Winding: None
• Vibration Sensor Indicator: No Vibration Sensor
• Winding Thermal 1: None
• Winding Thermal 2: None
