Balboa Water Group G6405 BP7 Spa Control System 4kW

Product Description

The Balboa Water Group G6405 BP7 is a compatible replacement for the BP501G3. This spa control system is one of the most feature and programming flexible systems available, capable of running up to 3 pumps plus a dedicated circulation pump. It supports all TP and SpaTouch topsides and BP ancillary products. This system can only be wired 220v.

• Supports all TP and SpaTouch topsides
• Supports all BP ancillary products (ControlMySpa, BBA, CZ, and Status Pro)
• Plug-N-Click Heater
• WiFi Included

Product Highlights

The Balboa BP7 spa control system features a TP500 control panel and a 4kW heater for single or multiple pump systems. It offers easy installation and service with integrated functionality.

Product Information

Standard Information

• Brand: BALBOA WATER GROUP
• Manufacturer Part Number: G6405-03

Technical Specifications

• Keypad Included: Included
• Supports: Pump1 + Blower/Pump2
• System Voltage: 230V
• Heater Wattage: 4.0kW
• Heater Type: Flow Thru
• Frequency (Hz): 50/60
• Alternate Part Numbers: 54219, 54216, 54217, 54220, VS300, VS500Z, VS501Z, VS501SZ, VS503SZ, VS504SZ, VS510SZ, VS510DZ, VS511Z, VS511SZ, 50-BP7-500-55-K, BP5 (replaced by BP7), BP7
• Voltage: 230~240V
• Model: BP7
• Hertz: 50 & 60 HZ
