B-Line GHB3025 Eaton Electrical GHB3025 Series C G Frame Bolt-On Molded Case Circuit Breaker

Product Description

The Eaton GHB3025 Series C G Frame Molded Case Circuit Breaker is designed for reliable protection in power distribution systems. This three-pole, fixed thermal and magnetic trip type breaker supports various applications, including switchboards and motor control centers. It operates at a current rating of twenty-five amps, suitable for both AC and DC applications up to six hundred volts. This breaker is an essential component for maintaining efficient and safe electrical systems.

• Current Rating: 25 Amps
• Voltage: 480Y/277 VAC, 125/250 VDC
• Frame Type: G

Product Highlights

This circuit breaker features a bolt-on mounting type and is suitable for applications like electrical assemblies, panels, and OEMs.

Product Information

Standard Information

• UPC: 786679172551
• GTIN: 00786679172551

Technical Specifications

• Catalog Number: GHB3025
• Brand: B-Line
• Type: Molded Case Circuit Breaker
• Frame: G
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupt Rating: 14 kAIC
• Country of Origin: Dominican Republic
• Mounting Type: Bolt-On
• Temperature Rating: 40°C
• Applications: Electrical assemblies, panels, motor control centers
