Aspen Manufacturing Z32 Pan Drain Pan 19.5 in Nylon

Product Description

The ASPEN MANUFACTURING Z32 PAN is a nylon drain pan designed to collect condensate from evaporator coil assemblies in residential and light-commercial HVAC systems. At 19.5 inches wide, it fits the BV1-24 uncased upflow/downflow coil and provides a corrosion-resistant secondary containment surface beneath the coil. Nylon construction resists the moisture, algae, and mild chemical exposure common in condensate environments. This pan is a direct service or replacement component installed by licensed HVAC technicians during coil service, system startup, or secondary-pan inspection.

This drain pan is specified for use with the BV1-24 uncased upflow/downflow coil in both upflow and downflow air handler orientations. It is suited for residential split-system or package unit installations where a secondary condensate pan is required beneath an evaporator coil. Proper condensate management is a code requirement in many jurisdictions, making correct pan selection and fitment essential during installation or service.

Key Features

• 19.5-inch width sized for the BV1-24 uncased upflow/downflow coil
• Nylon construction resists corrosion, moisture, and biological growth
• Compatible with both upflow and downflow coil orientations
• Lightweight material simplifies handling during installation or service
• Provides secondary condensate containment to protect equipment and structure

Compatibility

Designed for use with the BV1-24 uncased upflow/downflow evaporator coil.

Installation Notes

Installation is performed by a licensed HVAC technician. Disconnect and lock out power to the air handler before removing or repositioning the coil or drain pan. Verify the pan is seated level to ensure proper condensate drainage and confirm the condensate drain line is clear and properly pitched before returning the system to service. Follow local mechanical codes for secondary drain pan requirements and condensate disposal.
