Asc Engineered Solutions 560500241 Split Ring Hanger 2 in

Product Description

The ASC Engineered Solutions 560500241 is a galvanized split ring hanger designed to support pipe runs from threaded rod in mechanical, plumbing, and HVAC installations. Built from carbon steel with a galvanized finish, this hanger accepts a 3/8-inch threaded rod and is sized for 2-inch pipe. The split ring design allows the hanger to be installed around an existing pipe without threading the pipe through the ring, speeding up installation on new and retrofit projects. Plumbers, pipefitters, and mechanical contractors use this type of hanger for suspended pipe support in commercial and residential construction.

This hanger is suited for suspended pipe support in horizontal runs where pipe is hung from structure above using threaded rod. Typical applications include copper, steel, and plastic pipe systems in plumbing, hydronic heating, refrigeration piping, and HVAC refrigerant lines. The galvanized carbon steel construction provides corrosion resistance appropriate for indoor mechanical rooms, crawlspaces, and other standard building environments where mild corrosion exposure is a concern.

Key Features

• Split ring design allows installation on existing pipe without disassembly of adjacent fittings
• Galvanized carbon steel construction provides corrosion resistance for standard indoor applications
• Sized for 2-inch pipe with 3/8-inch threaded rod compatibility
• Lightweight at 0.31 pounds per unit, reducing load on threaded rod assemblies
• Consistent with common pipe hanger standards used in commercial and residential mechanical work

Compatibility

Designed as an OEM-style pipe support hanger for 2-inch pipe suspended from 3/8-inch threaded rod in standard mechanical, plumbing, and HVAC piping systems.

Installation Notes

Installation is typically performed by licensed plumbers or pipefitters following applicable IPC or IFGC hanger spacing requirements for the pipe material and fluid being carried. Power down or isolate the system before working on pressurized lines. The split ring should be fully closed and secured to the threaded rod before loading the pipe. Do not exceed the load rating for the rod size and hanger combination as specified by the authority having jurisdiction or the applicable mechanical code.

Technical Specifications

• Material: Carbon Steel
• Finish: Galvanized
• Pipe Size: 2 inches
• Rod Size: 3/8 inches
• Type: Split Ring Hanger
• Weight: 0.31 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 560500241
