Asc Engineered Solutions 560500233 Split Ring Hanger 1.5 in

Product Description

The ASC Engineered Solutions 560500233 is a galvanized split ring hanger designed to support pipe in suspended and overhead installations. Fabricated from carbon steel with a galvanized finish, it provides corrosion resistance suited to mechanical rooms, crawlspaces, and other environments where moisture exposure is a concern. The hanger accepts a 3/8 inch threaded rod and is sized for 1.5-inch pipe. Licensed plumbers, pipefitters, and mechanical contractors install this type of hanger during rough-in on both new construction and retrofit projects.

This split ring hanger is used in residential and light commercial plumbing and mechanical piping systems where pipe must be suspended from structural members via threaded rod. The split ring design allows the hanger to be installed around the pipe without threading through from the end, making it practical for retrofit or tight-access applications. It is appropriate for horizontal runs of copper, steel, or compatible pipe in standard pipe support layouts.

Key Features

• Galvanized carbon steel construction for corrosion resistance in damp or humid environments
• Sized for 1.5-inch pipe, compatible with standard pipe dimensions
• Accepts 3/8 inch threaded rod for secure suspended mounting
• Split ring design allows installation around pipe without end-feeding
• Lightweight at 0.24 pounds per unit for easy handling during installation

Compatibility

Designed as an OEM-style replacement and standard fitment split ring hanger for 1.5-inch pipe systems requiring 3/8 inch threaded rod suspension in plumbing and mechanical piping applications.

Installation Notes

Installation is typically performed by licensed plumbers or pipefitters in accordance with applicable plumbing codes such as the IPC. Shut off the piping system and relieve pressure before modifying any pipe support arrangement. Ensure the threaded rod and structural attachment point are rated for the load of the supported pipe, including fluid weight. Do not overtighten the hanger hardware, as this can deform the pipe or compromise the hanger seating.

Technical Specifications

• Material: Carbon Steel
• Finish: Galvanized
• Pipe Size: 1.5 inches
• Rod Size: 3/8 inch
• Type: Split Ring Hanger
• Weight: 0.24 pounds per unit

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 560500233
