Asc Engineered Solutions 560018980 Copper Split Ring Hanger

Product Description

The ASC Engineered Solutions 560018980 is a copper split ring hanger designed to support pipe in suspended installations. The split ring design allows the hanger to be installed around an existing pipe run without disassembling the line. It accepts a 3/8 inch threaded rod, which connects the hanger to overhead structure. Sized for 2 inch pipe, this hanger is a standard component in plumbing, HVAC, and mechanical piping systems. Plumbers and pipefitters install this type of hardware during rough-in and retrofit work in both new construction and existing buildings.

This split ring hanger is suited for residential and light commercial applications where copper pipe support is required. It is commonly used in domestic water supply systems, hydronic heating piping, and other mechanical systems where copper is the pipe material of choice. The 3/8 inch rod size is a standard specification in suspended pipe support assemblies, making this hanger compatible with widely available threaded rod stock.

Key Features

• Copper construction provides corrosion resistance suitable for wet and mechanical room environments
• Split ring design allows installation around an existing pipe without cutting or disassembly
• Accepts 3/8 inch threaded rod for connection to overhead structure
• Sized for 2 inch pipe diameter
• Lightweight at 0.23 pounds per unit for easy handling and bulk installation

Compatibility

Designed as an OEM-style replacement and standard-fit split ring hanger for 2 inch copper pipe suspended support applications using 3/8 inch threaded rod assemblies.

Installation Notes

Installation is typically performed by licensed plumbers or pipefitters following applicable IPC and local mechanical code spacing requirements for pipe support. Shut off water supply and relieve system pressure before repositioning or replacing existing hangers in a live system. Use appropriate tooling to tighten the rod connection to the structural support without over-torquing the copper ring. Ensure the hanger is positioned to allow for pipe expansion and contraction as required by the system design.

Technical Specifications

• Material: Copper
• Pipe Size: 2 inches
• Rod Size: 3/8 inches
• Type: Split Ring Hanger
• Weight: 0.23 pounds per unit

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 560018980
