Asc Engineered Solutions 560018974 Copper Split Ring Hanger

Product Description

The ASC ENGINEERED SOLUTIONS 560018974 is a copper split ring hanger designed to support 1-inch pipe from 3/8-inch threaded rod. Split ring hangers provide a secure, removable cradle around the pipe, allowing the pipe to be seated without threading through the support. The all-copper construction makes this hanger well suited for copper pipe systems where dissimilar-metal contact must be avoided. Plumbers and mechanical contractors install these hangers in overhead or structural applications where pipe must be suspended from rod-based support systems.

This hanger is used in residential and commercial plumbing and mechanical systems to suspend 1-inch copper pipe from 3/8-inch threaded rod. Typical applications include domestic water supply lines, hydronic heating piping, and other copper piping systems routed through framed ceilings, open joists, or structural steel. The split ring design speeds installation by snapping around the pipe rather than requiring pipe removal or disassembly of adjacent fittings.

Key Features

• All-copper construction eliminates galvanic corrosion risk when used with copper pipe
• Split ring design allows pipe to be installed without threading through the hanger
• Sized for 1-inch pipe with a 3/8-inch rod opening for standard threaded rod suspension
• Lightweight at 0.13 pounds per unit, reducing load impact on support structures
• Compatible with standard 3/8-inch all-thread rod commonly used in plumbing and mechanical hangers

Compatibility

Designed as an OEM-style replacement or new-installation split ring hanger for 1-inch copper pipe systems suspended from 3/8-inch threaded rod.

Installation Notes

Installation is typically performed by licensed plumbers or mechanical contractors following IPC and local plumbing code requirements for pipe support spacing and hanger type. Shut off and drain the pipe system before repositioning or replacing existing hangers. Use appropriately rated 3/8-inch threaded rod and fasteners rated for the pipe load and installation surface. Do not use this hanger with pipe materials or sizes other than those specified, as improper fitment can cause pipe stress or movement.

Technical Specifications

• Material: Copper
• Pipe Size: 1 inch
• Rod Size: 3/8 inch
• Type: Split Ring
• Weight: 0.13 pounds per unit

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 560018974
