ASC Engineered Solutions 4381002710 4 150 316/L RF THRD FLG

Product Description

The ASC Engineered Solutions Flange, MPN 4381002710, is designed for reliable pipe connections. This raised face flange is ideal for various piping applications requiring strong and durable joints.

• Raised face type for better sealing
• Made from forged 316L stainless steel
• Suitable for a pressure class of 150 lb

Product Highlights

This flange includes eight bolt holes for secure attachment and is used with threaded connections in piping systems.

Product Information

Standard Information

• Manufacturer: ASC Engineered Solutions
• UPC: 092201348500

Technical Specifications

• Bolt Circle Diameter: 8-1/2 in
• Bolt Hole Size: 0.88 in
• Connection Type: Thread
• Hub Diameter: 6.44 in
• Length Through Hub: 1.31 in
• Material: Forged 316L Stainless Steel
• Nominal Size: 4 in
• Number of Bolt Holes: 8
• Outside Diameter: 9 in
• Pressure Class: 150 lb
• Series: S1016TH
• Thickness: 0.94 in
