Asc Engineered Solutions 390119220 Grooved Tee 6 in

Product Description

The ASC Engineered Solutions 390119220 is a 6-inch galvanized grooved tee fitting designed for use in grooved piping systems. Manufactured from ductile iron with a galvanized finish, this tee provides a branch connection in pressurized piping networks. It is installed using standard grooved couplings and fittings, eliminating the need for welding or threading at the branch point. At 25.70 pounds, the fitting is built for demanding mechanical piping applications. Licensed plumbers, pipefitters, and mechanical contractors are the primary installers for this type of fitting.

This grooved tee is suited for commercial and industrial piping systems including fire suppression, HVAC hydronic distribution, and general mechanical piping. The 6-inch size fits main distribution runs where a branch takeoff is required. The galvanized coating provides corrosion resistance appropriate for wet-system environments and exposed indoor installations.

Key Features

• 6-inch nominal pipe size for main-line branch connections
• Ductile iron construction for high-strength performance in pressurized systems
• Galvanized finish for corrosion resistance in wet or humid environments
• Grooved-end design compatible with standard grooved coupling systems
• No welding or threading required at the connection point

Compatibility

Designed as an OEM-style grooved fitting for use with standard 6-inch grooved piping systems and compatible grooved couplings per AWWA and ANSI pipe specifications.

Installation Notes

Installation should be performed by a licensed pipefitter or plumber in accordance with applicable mechanical codes. Depressurize and drain the piping system completely before removing or installing any grooved fittings. Inspect gaskets and coupling housings for wear or damage before assembly. Torque coupling fasteners per the coupling manufacturer specifications, not those of the tee fitting itself.

Technical Specifications

• Fitting Size: 6 inches
• Fitting Material: Ductile Iron
• Finish: Galvanized
• Item Weight: 25.70 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390119220
