Asc Engineered Solutions 390119147 Grooved Tee 3 in

Product Description

The ASC Engineered Solutions 390119147 is a 3-inch galvanized grooved tee fitting designed for use in grooved piping systems. Manufactured from ductile iron with a galvanized finish, this tee provides a corrosion-resistant branch connection in mechanical piping assemblies. At 5.93 pounds, the fitting is sized for standard grooved-end pipe connections and is installed by licensed plumbers, pipefitters, and mechanical contractors working on commercial and industrial piping systems. The grooved-end design eliminates the need for threading or welding, allowing for faster assembly and disassembly during maintenance.

This fitting is suited for commercial and industrial mechanical piping systems where a 3-inch branch takeoff is required. Typical applications include HVAC hydronic distribution, fire protection, and general mechanical piping. The galvanized exterior finish makes it appropriate for installations where mild corrosion resistance is a priority. It is compatible with standard grooved couplings and housings designed for 3-inch pipe, and is commonly used in both new construction and retrofit mechanical rooms.

Key Features

• Ductile iron construction for strength and durability in pressurized piping systems
• Galvanized finish provides corrosion resistance for mechanical and HVAC applications
• 3-inch grooved-end connections for use with standard grooved couplings
• No threading or welding required, reducing installation time
• Grooved tee configuration allows a branch connection in a straight pipe run

Compatibility

Designed as an OEM-style replacement and standard grooved fitting for use with 3-inch grooved-end piping systems in commercial HVAC, fire protection, and industrial mechanical applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical codes. Depressurize and drain the piping system fully before removing or installing any grooved fittings. Use properly rated grooved couplings and follow the coupling manufacturer torque and assembly guidelines. Inspect groove dimensions on the pipe end to confirm they meet the fitting specifications before assembly.

Technical Specifications

• Fitting Size: 3 inches
• Fitting Material: Ductile Iron
• Finish: Galvanized
• Item Weight: 5.93 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390119147
