Asc Engineered Solutions 390117240 Grooved 45 Elbow 6 in

Product Description

The ASC Engineered Solutions 390117240 is a galvanized grooved 45-degree elbow fitting designed for use in grooved piping systems. Manufactured from ductile iron with a galvanized finish, this 6-inch elbow provides a 45-degree change of direction in mechanical piping installations. It is sized at 6 inches and weighs 11.71 pounds, making it suited for larger-diameter piping runs. Licensed pipefitters and mechanical contractors install this fitting as part of grooved coupling systems in commercial and industrial pipe networks.

This fitting is used in commercial and industrial mechanical piping systems where grooved-end pipe connections are specified. The galvanized finish provides corrosion resistance suitable for wet or exposed installations. It fits into 6-inch grooved piping systems and is a standard directional fitting in hydronic, fire protection, and HVAC piping layouts where a 45-degree offset is required.

Key Features

• 45-degree elbow configuration for directional pipe routing
• 6-inch fitting size for larger-diameter grooved piping systems
• Ductile iron construction for high-strength mechanical performance
• Galvanized finish for corrosion resistance in exposed or wet environments
• Grooved-end design for use with standard grooved couplings and housings

Compatibility

Designed as an OEM-style grooved fitting for use with standard 6-inch grooved coupling systems in commercial mechanical piping applications.

Installation Notes

Installation is performed by licensed pipefitters or mechanical contractors following applicable codes including NFPA and ASME standards for grooved piping systems. Isolate and depressurize the piping system fully before removing or installing any grooved fittings. Inspect the pipe-end groove dimensions for compliance with the coupling manufacturer specifications before assembly. Do not overtighten coupling housing bolts beyond the manufacturer-specified fastener engagement point.

Technical Specifications

• Fitting Size: 6 inches
• Elbow Degree: 45 degrees
• Fitting Material: Ductile Iron
• Finish: Galvanized
• Item Weight: 11.71 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390117240
