Asc Engineered Solutions 390080059 Epdm Gasket 5 in

Product Description

The ASC ENGINEERED SOLUTIONS 390080059 is a 5-inch EPDM gasket designed for use with the Gruvlok 7012 grooved flange fitting. EPDM rubber provides a reliable, weather-resistant seal suited for water and mechanical piping systems. This gasket seats directly into the grooved flange to create a leak-free connection at the flange joint. Licensed plumbers and pipefitters install this component as part of grooved piping assemblies in commercial and industrial applications. At 0.10 pounds, the gasket is a lightweight but critical sealing element that keeps grooved flange joints tight and properly sealed under system pressure.

This gasket is intended for use with the Gruvlok 7012 grooved flange in 5-inch pipe configurations. Grooved flange systems are common in commercial HVAC hydronic piping, fire protection, and industrial process piping where fast, reliable mechanical connections are required. The EPDM compound is well-suited for cold and hot water service, making it appropriate for a range of building mechanical systems.

Key Features

• EPDM rubber construction for durable, weather-resistant sealing performance
• Sized for 5-inch grooved flange applications
• Designed specifically for use with the Gruvlok 7012 grooved flange fitting
• Lightweight at 0.10 pounds for easy handling during installation
• Green color coding for visual identification of EPDM compound

Compatibility

Designed for use with the Gruvlok 7012 grooved flange fitting in 5-inch pipe size configurations.

Installation Notes

Installation is typically performed by licensed plumbers or pipefitters as part of a grooved mechanical piping assembly. Depressurize and drain the piping system completely before disassembling any grooved flange joint. Inspect the gasket seating groove for debris or damage before placing the gasket. Follow the fitting manufacturer torque guidelines and applicable IPC or IFGC code requirements for the specific system type.

Technical Specifications

• Gasket Material: EPDM
• Fitting Size: 5 inches
• Compatible Fitting Material: Ductile Iron
• Item Weight: 0.10 pounds

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 390080059
