Asc Engineered Solutions 390016947 Gruvlok 8 in Tee

Product Description

The ASC Engineered Solutions 390016947 is a Gruvlok 7060 grooved painted tee designed for use in grooved piping systems. This ductile iron tee fitting measures 8 inches and connects three sections of grooved pipe in a tee configuration. It ships with a painted exterior finish that provides baseline corrosion protection during storage and installation. The fitting is suited for mechanical contractors and pipefitters working on fire protection, HVAC, and industrial piping applications where grooved mechanical joining is specified. At 40.53 pounds, it is a heavy-duty component intended for permanent installation in medium- to large-diameter pipe systems.

This tee fitting is used in grooved piping systems across commercial and industrial applications, including HVAC hydronic distribution, fire sprinkler mains, and general process piping. The 8-inch size is common in large-tonnage chiller plants, boiler distribution headers, and primary loop piping runs. Installation is performed by licensed pipefitters or mechanical contractors using compatible grooved couplings and the appropriate roll-grooving or cut-grooving tooling on the mating pipe ends.

Key Features

• Ductile iron construction for high strength and impact resistance in demanding piping applications
• 7060 series tee configuration for grooved mechanical joining systems
• 8-inch fitting size suitable for large-diameter commercial and industrial piping
• Painted exterior finish provides corrosion protection during storage and installation
• Grooved end connections designed for use with standard grooved couplings and gaskets

Compatibility

Designed as an OEM-style grooved tee fitting for use in standard 8-inch grooved mechanical piping systems. Specific system or coupling compatibility was not provided in the available product data.

Installation Notes

Installation of this fitting should be performed by a licensed pipefitter or qualified mechanical contractor in accordance with applicable mechanical codes. Ensure pipe ends are properly grooved to the correct groove profile and dimensions before assembly. Inspect the gasket and coupling hardware for compatibility before torquing coupling bolts. Support pipe runs adequately near the fitting to prevent stress on the grooved connections.

Technical Specifications

• Fitting Material: Ductile Iron
• Fitting Size: 8 inches
• Item Weight: 40.53 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390016947
