Asc Engineered Solutions 361123508 Reducing Tee 1x3/4 in 3000 Lb

Product Description

The ASC ENGINEERED SOLUTIONS 361123508 is a forged steel threaded reducing tee rated for 3000 lb pressure service. This fitting connects a 1-inch main run to a 3/4-inch branch outlet using tapered pipe threads on all three openings. It is built for high-pressure piping systems where a reliable, compact transition between pipe sizes is required. Licensed plumbers and pipefitters install this type of fitting in industrial, commercial, and mechanical piping assemblies. At 3.33 pounds, the forged steel construction provides the wall strength needed to handle demanding service conditions.

This reducing tee is suited for use in high-pressure steam, water, oil, and gas piping systems that call for a 3000 lb Class forged steel threaded fitting. It is a standard choice for mechanical rooms, industrial process lines, and commercial plumbing installations where reducing the branch line from 1 inch to 3/4 inch is needed. The threaded connection style allows for field assembly without welding, making it practical for retrofit and maintenance work.

Key Features

• Forged steel construction rated for 3000 lb pressure class service
• Threaded reducing configuration with 1-inch run and 3/4-inch branch
• All-threaded openings allow tool-only installation with no welding required
• Compact, heavy-wall forged body handles high-pressure and high-temperature piping applications
• 3.33-pound unit weight consistent with standard forged Class 3000 fittings

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 3000 lb Class threaded forged steel piping systems requiring a 1-inch by 3/4-inch reducing tee connection.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes. De-pressurize and drain the system fully before removing or installing any threaded fitting. Apply an approved pipe thread sealant or PTFE tape to male threads before assembly, and tighten to the appropriate engagement using pipe wrenches. Do not over-tighten, and do not apply heat to assist makeup on a threaded forged steel fitting.

Technical Specifications

• Fitting Material: Forged Steel
• Fitting Size: 1 inch x 3/4 inch
• Pressure Class: 3000 lb
• Type: Threaded Reducing Tee
• Weight: 3.33 pounds

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 361123508
