Asc Engineered Solutions 361109408 Forged Steel Street Elbow

Product Description

The ASC Engineered Solutions 361109408 is a 90-degree forged steel street elbow rated for 3000 lb pressure class service. It features male threaded connections on both ends in a street configuration, allowing a direction change without a nipple between fittings. Sized at 3/8 inch, it is built for high-pressure piping applications in industrial, mechanical, and process systems. At 0.50 pounds, the compact forged steel construction delivers the wall thickness and thread integrity required for demanding service conditions. Licensed plumbers, pipefitters, and mechanical contractors install this type of fitting in steam, hydraulic, and compressed-air lines where a compact 90-degree turn is needed.

This street elbow is suited for residential and commercial mechanical rooms, industrial process piping, and compressed-air distribution systems where space constraints make a street configuration preferable to a standard elbow-plus-nipple assembly. The 3/8 inch size fits small-bore branch lines and instrumentation runs. Its 3000 lb pressure class makes it appropriate for high-pressure steam and hydraulic piping where standard 150 lb or 300 lb fittings are not rated for the service conditions.

Key Features

• 90-degree street elbow configuration eliminates the need for a separate nipple between fittings
• Forged steel construction provides strength and thread integrity for high-pressure service
• 3000 lb pressure class rating suitable for steam, hydraulic, and compressed-air applications
• 3/8 inch size fits small-bore branch and instrumentation lines
• Male threaded ends for direct connection into female-threaded fittings or equipment ports

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 3/8 inch female-threaded pipe systems requiring a 90-degree directional change in high-pressure service.

Installation Notes

Installation should be performed by a licensed pipefitter or plumber in accordance with applicable mechanical and piping codes. Depressurize and isolate the line completely before removing or installing any threaded fittings. Apply appropriate thread sealant or PTFE tape to all male threads before assembly, following the sealant manufacturer's instructions for the service medium. Do not over-torque forged steel fittings, and verify that the pressure class of all adjacent fittings and valves is compatible with the system operating pressure.

Technical Specifications

• Fitting Size: 3/8 inches
• Elbow Degree: 90 degrees
• Type: Street Elbow Male Threaded
• Pressure Class: 3000 lb
• Fitting Material: Forged Steel
• Item Weight: 0.50 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 361109408
