Asc Engineered Solutions 308007905 Reducing Flange 1.5in Class 125

Product Description

The ASC Engineered Solutions 308007905 is a Class 125 black cast iron reducing flange designed for use in low-pressure piping systems. This domestic-made fitting transitions from a 1.5-inch pipe connection to a 7.5-inch outer diameter mounting face, making it suitable for joining pipe runs to pumps, valves, and equipment flanges where a size reduction is required. The black coating provides basic corrosion resistance for above-ground service. Weighing 8.5 pounds, this is a heavy-duty, full-cast fitting intended for licensed plumbers and pipefitters working on commercial or industrial piping assemblies.

This reducing flange is used in low-pressure water, drainage, and general service piping applications. Class 125 cast iron flanges are commonly found in commercial mechanical rooms, pump connections, and industrial process piping. The fitting is suited for above-ground installations where standard flange bolt patterns and face dimensions are required. Plumbers and pipefitters install this type of flange as part of bolted flange assemblies on systems operating within Class 125 pressure ratings.

Key Features

• Cast iron construction provides durability for commercial and industrial piping service
• Class 125 pressure rating suitable for low-pressure water and general service applications
• Reducing design transitions 1.5-inch pipe to a 7.5-inch outer diameter flange face
• Black coating for basic surface protection on above-ground installations
• Domestically manufactured fitting

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Class 125 cast iron flange assemblies in commercial and industrial low-pressure piping systems.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable codes including the IPC and local mechanical codes. Shut off and depressurize the system completely before removing or installing any flange fitting. Use appropriate gaskets and fasteners rated for Class 125 service when assembling the bolted flange joint. Do not overtighten bolts unevenly — follow a cross-pattern sequence to ensure proper gasket seating and a leak-free joint.

Technical Specifications

• Fitting Size: 1.5 inches
• Outer Diameter: 7.5 inches
• Pressure Class: 125 pounds
• Material: Cast Iron
• Coating: Black
• Type: Reducing Flange
• Weight: 8.5 pounds
• Origin: Domestic

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 308007905
