AS 6145013.002 Ultima Manual Urinal Flush Valve 0.125 GPF

Product Description

The AS Ultima 6145013.002 is a manual urinal flush valve designed for efficient performance. This valve is constructed from brass and includes innovative features to enhance functionality. It is suited for urinals with a three-quarter inch top spud and includes a non-hold open handle for automatic shut-off after flushing.

• Constructed from durable brass material
• Includes self-cleaning wiper spring technology
• Compatible with left or right-handed installations

Product Highlights

This urinal flush valve offers reliability and ease of maintenance, making it ideal for high-use environments. The diaphragm is made from EvoLast material, which resists chlorine and chloramine for long-lasting durability.

Product Information

Standard Information

• Brand: American Standard
• MPN: 6145013.002

Technical Specifications

• Series: Ultima
• Material: Brass
• Flow Rate: 0.125 GPF
• Inlet Connection: 3/4-inch exposed top spud
• Outlet Connection Type: NPT
• Pressure Rating: 25 - 80 PSI
• Height: 14-5/8 inches
• Width: 4-1/4 inches
