Honeywell L4006E1125 Aquastat Controller High Limit Manual Reset

Product Description

The Honeywell L4006E1125 Aquastat Controller is a high limit manual reset device designed to control temperature in heating systems. This model is suitable for boiler applications, providing safety and precision in temperature management.

• High limit manual reset feature
• Temperature range from 100 to 200 degrees Fahrenheit
• Horizontal or vertical mounting options

Product Highlights

The Honeywell L4006E1125 Aquastat Controller is built for use in boilers and storage tanks. It operates with a snap-acting switch and offers easy external adjustments.

Product Information

Standard Information

• MPN: L4006E1125
• Brand: Honeywell

Technical Specifications

• Temperature Range: 100 to 200 degrees Fahrenheit
• Differential: Manual Reset
• Switch Type: SPST
• Insulation Depth: 3 inches
• Mounting Type: Horizontal/Vertical
• Enclosure Type: Totally Enclosed
• Capillary Length: 3 inches
• Bulb Size: 3/8 x 2-7/8 inches (Copper)
• Spud Size: 1/2 inch NPT
• Dimensions: 5-5/8 inches H x 2 inches W x 2-1/8 inches D
