Appleton UCSSA23SRC 3POS 4CKT SEL SW

Product Description

Appleton UCSSA23SRC is a 3-position, 4-circuit selector switch designed for control operations in various environments. This product is suitable for washdown areas and highly corrosive applications. It is ideal for operating motors and can be integrated with various push buttons and selector switches. The switch allows for remote control capabilities, granting reliable performance in hazardous locations.

• Factory sealed design eliminates the need for additional sealing fittings.
• Corrosion-resistant with stainless steel screws and high-quality gasket.
• Available with various operational configurations to suit specific operational needs.

Product Highlights

Appleton UCSSA23SRC provides a versatile solution for machine controls in damp environments. The selector switch features robust design attributes to ensure safety and functionality in hazardous conditions.

Product Information

Standard Information

• Brand: Appleton Electric
• Manufacturer: Appleton Electric

Technical Specifications

• Catalog Number: UCSSA23SRC
• UPC: 78138180636
• Contact Configuration: 6NO-6NC
• Number of Positions: 3
• Throw: Left-Center-Right
• Enclosure Rating: Class I Div 1 and 2 Group B C D, NEMA 3/3R/4/4X
• Operation Type: Maintained/Momentary/Momentary
• Application: Control in washdown and corrosive areas
