Appleton TA75-M Unilets Conduit Outlet Body 3/4 in

Product Description

The APPLETON TA75-M Unilets Conduit Outlet Body is a type TA conduit outlet body with a 3/4 in hub. It features four hubs and a 7 cu-in capacity. Designed to connect and change the direction of conduit runs, it also allows connections for branch runs, serves as a pulling fitting, and permits access to conductors for splicing and maintenance.

• Smooth, rounded integral bushing in hubs protects conductor insulation
• Accurately tapped, tapered threads for tight, rigid joints and excellent ground continuity
• Form 35 malleable iron UNILETS high tensile strength and ductility

Product Highlights

This conduit outlet body is ideal for use with rigid steel, rigid aluminum conduit, and IMC. It provides openings for splicing and allows connections for branch runs.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: TA75-M
• Country of Origin: MX

Technical Specifications

• Brand: Appleton
• Part Number #: TA75M
• UNSPSC: 39131708
• Hub Size: 3/4 in
• Hubs: 4
• Capacity: 7 cu-in
• Form: Form 35 Form
• Enclosure: NEMA FB-1
• Connection: Tapered FNPT
• Mounting: Surface
• Material: Malleable Iron
• Type: Type TA
• Family / Style: Form 35
• Manufacturer Part Number: TA75-M
• Manufacturer: Appleton
• Product Series: Form 35 Malleable Iron
• Family Series: Appleton Conduit Outlet Bodies, Form 35 Malleable Iron Series
• Description: Form 35 UNILETS Type TA Conduit Outlet Body, Hub Size: 3/4 IN, Form: 35, Length: 6.06 IN, Material: Malleable Iron, Finish: Triple-Coat Zinc Electroplate, Chromate And Epoxy Powder Coat, Connection: Tapered Female Threaded, Standard: UL
• Style: Threaded Iron
• Shape: TA
• Number of Hubs: 4
• Cover Included: No
• Gasket Included: No
• Conduit Type: IMC (Intermediate Metal Conduit), RMC (Rigid Metal Conduit)
• Connection Type: Tapered FNPT
• Trade Size: 3/4 "
• Composition: Malleable Iron
• Hazardous Location: Yes
• Approvals: CSA, UL
• Application: For Use With Rigid Steel, Rigid Aluminum Conduit And IMC
• ARRA Compliant: Y
• Buy American Compliant: N
• Catalog Number: TA75M
• Country of Origin: MX
• EU RoHS Indicator: N
• Finish: Zinc Electroplate/Chromate/Epoxy Powder Coat
• Sub Brand: UNILETS
• Standard: UL 514A, UL 514B, UL File Number E2527, CSA C22.2 No. 18.3, CSA 065183, NEMA FB-1
• Standards: ARRA CompliantUL 514B File No. E2527C22.2 No. 18.3/065183 Certified
• Diameter: 3/4 in
• Component: Conduit Body
