Appleton HS20F750B Encapsulated Single Phase Buck-boost Transformers 0.75 kVA

Product Description

The Appleton HS20F750B is an encapsulated single-phase buck-boost transformer. This transformer operates at 120 x 240 VAC - 16/32 VAC with a 0.75 kVA rating and a frequency of 60 Hz. It is designed with a N3R enclosure for protection and wall mounting.

• Encapsulated single-phase design
• Operates at 120 x 240 VAC - 16/32 VAC
• Features a N3R enclosure for protection

Product Highlights

The Appleton buck-boost transformer is ideal for voltage adjustments in various applications. Its encapsulated design and N3R enclosure ensure durability and protection in demanding environments.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: HS20F750B

Technical Specifications

• Brand: Appleton Emerson
• Depth: 5 in
• Primary Voltage: 120 x 240 VAC
• Frequency Band: 60 Hz
• Transformer Style: Encapsulated
• NEMA Rating: NEMA 3R
• Type: Buck Boost Transformer
• Number of Phases: 1 Phase
• Voltage: 120 x 240 VAC - 16/32 VAC
• Secondary Voltage: 16/32 VAC
• Width: 6 in
• Height: 10 in
• Mounting Type: Wall
• Insulation Temperature: 180 deg C
• Winding: Copper
• KVA Rating: 0.75 kVA
• Series: SolaHD
• Enclosure Type: N3R Enclosure
