Appleton GRCA50A GR Unilet Type CA 1/2 inches

Product Description

The APPLETON GRCA50A is a 1/2" CA-Type conduit body. Explosionproof and dust-ignitionproof, it is designed for use with threaded metal conduit. The malleable iron body offers high tensile strength and resistance to corrosion, impact, and shock. Features accurately tapped, tapered hub threads for tight joints and ground continuity.

• Explosionproof and dust-ignitionproof
• High tensile strength, ductility, and resistance to corrosion
• Accurately tapped, tapered hub threads for tight, rigid joints

Product Highlights

This conduit outlet box provides access for maintenance and allows connection of different conduit lengths. It is ideal for indoor and outdoor classified locations.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: GRCA50A
• Country of Origin: United States

Technical Specifications

• Product Series: GR
• Manufacturer Part Number: GRCA50A
• Manufacturer: Appleton
• Description: Explosionproof Conduit Outlet Box, Style CA, Hub Size 1/2 Inch, Hub Type External, Number of Hubs 3, Hub Location 2 Side, 1 Down, Capacity 18 Cu Inch, Shape Round, Cover Type Externally Threaded, Cover Opening Diameter 3.38 Inch, Enclosure Class I Div 1
• Connection Type: Threaded
• Style: GRCA
• Shape: CA
• Number of Hubs: 3
• Conduit Type: IMC (Intermediate Metallic Conduit), RMC (Rigid Metallic Conduit)
• Composition: Aluminum
• Cover Composition: Aluminum
• Cover Included: Yes
• Cover Type: Blank
• Gasket Included: Yes
• Protection Rating: Indoor, Outdoor
• Approvals: CSA, UL
• Comments: Corrossion, impact & shock resistance
• Brand: Appleton
• UPC: 781381621694
• Sub Brand: Unilet
• Item Name: Type CA Conduit Outlet Box
• Type: 3-Inlet, Round, Explosionprrof
• Trade Size: 1/2 in
• Material: Aluminum
• Mounting Type: Wall/Ceiling
• Includes: Screwed Cover
• Component: Conduit
• Part No.: GRCA50A
• Category: Conduit/Fitting
