Appleton EFKB345 Selector Switch Cover Assembly

Product Description

The Appleton EFKB345 is a selector switch cover assembly designed to operate in hazardous environments. It features a maintained operation and offers a contact rating of ten amps at six hundred volts AC. The assembly is ideal for use in chemical and petrochemical plants, providing reliable control for motors and other machinery. The enclosure is NEMA rated for protection against dust and moisture.

• Explosionproof and dust-ignitionproof design
• Factory sealed to eliminate additional sealing fittings
• Compatible with magnetic starters for remote motor control

Product Highlights

Developed for various industrial applications, the EFKB345 is built to withstand harsh conditions while ensuring safety and reliability during operation.

Product Information

Standard Information

• Brand: Appleton
• MPN: EFKB345

Technical Specifications

• Contact Rating: 10 AMP at 600 VAC
• Contact Configuration: 2 NO/2 NC
• Enclosure: NEMA 3, 7CD, 9EFG
• Number of Steps: 3
• Application: For conjunction with contactors or magnetic starters for remote control of motors
• Mounting: Surface with 1/2 inch NPSM
• Country of Origin: Mexico
• Construction Material: Aluminum actuator and cover
