APPLETON EFKB12 RELAYS & SWITCHES
APPLETON Appleton EFKB12 Selector Switch Cover Assembly
APPLETON Appleton EFKB12 Selector Switch Cover Assembly

Appleton EFKB12 Selector Switch Cover Assembly

Brand: APPLETON
SKU: EFKB12
Availability: Out Of Stock
Manuals:
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Appleton EFKB12 Selector Switch Cover Assembly provides reliable operation in hazardous environments. This assembly is designed for controlling motors and other equipment in classified areas where flammable vapors or dust may be present. The EFKB12 features a robust design to ensure safety and compliance with industry standards.

  • Explosionproof and dust-ignitionproof, ideal for chemical plants and refineries.
  • Factory sealed, eliminating additional sealing fittings.
  • Compatible with contactors and magnetic starters for remote motor control.

Product Highlights

Designed for hazardous locations, the EFKB12 ensures that arcing does not ignite surrounding materials during operation.

Product Information

Standard Information

  • Brand: Appleton
  • MPN: EFKB12
Technical Specifications
Catalog Number
EFKB12
Contact Rating
10 AMP at 600 VAC
Contact Configuration
1 NO/1 NC
Enclosure
NEMA 3, 7CD, 9EFG
Number of Steps
2
Application
Remote control of motors with contactors or magnetic starters
Material
Aluminum actuator with copper-free aluminum enclosure
Operation Type
Maintained with left-right throw
