Product Description
Appleton BUB300-A is a conduit outlet body, cover and gasket made from aluminum. This product is designed for use with rigid conduit and IMC. The overall dimensions are twenty-two point eighty-eight inches long, four point sixty-three inches wide, and seven point thirty-one inches high. It features a three-inch hub size with threaded installation.
- Material: Epoxy powder coated copper free aluminum
- Two hubs for efficient conduit management
- UL and CSA approved for safety compliance
Product Highlights
This conduit body is ideal for applications requiring a durable and versatile connection point for large conductors. It allows for straight, angled, and tap connections.
Product Information
Standard Information
-
Manufacturer: Appleton Electric
-
Brand Name: Unilet
Technical Specifications
-
Size: Twenty-two point eighty-eight inches length x four point sixty-three inches width x seven point thirty-one inches height
-
Hub Size: Three inches
-
Material: Epoxy powder coated copper free aluminum body, neoprene gasket, stainless steel screw
-
Approval: UL 514B, CSA C22.2, NEC, CEC
-
Configuration: UB
-
Access Opening: Back
-
Number of Hubs: Two
-
Installation: Threaded
