Appleton 7481V AC/Flex Connector Straight 1/2 inches Diameter

Product Description

The APPLETON 7481V is an armored cable and flexible metal conduit connector with a straight body. It is designed to ground and secure armored cable and flexible metal conduit to boxes and enclosures. It has a 1/2 Inch Diameter and a cable range of 0.75 - 0.94 Inch.

• Male NPS thread connection
• 0.44 in thread length
• Zinc Electroplated

Product Highlights

The APPLETON 7481V connector is made of malleable iron with zinc plating and is furnished with a locknut.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: 7481V
• Country of Origin: United States

Technical Specifications

• Material: Malleable Iron
• Diameter: 1/2 in
• Brand: Appleton
• Suitable For Use With: Armored Cable and Flexible Metal Conduit
• Trade Size: 1/2 in
• Type: Straight
• Application: For grounding and securing nonmetallic sheathed and service entrance cable to boxes and enclosures
• Standard & Approvals: UL 514B/E14814 Listed, CSA 065178/C22.2 No 18.3 Certified, NEMA FB-1, RoHS Compliant
• Cable Openings: 0.59 - 0.94 in
• Finish: Zinc Plated
• Model: 7481V
• MPN: 7481V
• Country of Origin: United States
