Appleton 7400S Ner 4 in

Product Description

The Appleton 7400S series steel EMT compression connectors ground and secure EMT raceways to boxes and enclosures. The 7000S Series have a male NPS threaded hub and are available with or without an insulated throat. Features a zinc electroplated finish and a 4-inch trade size.

• Male hub NPS thread connection
• Concrete tight
• 3 3/16IN Dia X 5 1/16IN Length

Product Highlights

Appleton 7400S series EMT compression connectors are designed for grounding and securing EMT raceways. They feature a steel construction with a zinc electroplated finish.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: 7400S
• Country of Origin: IN

Technical Specifications

• Series: 7000S
• Material: Steel
• Trade Size: 4 in
• Country of Origin: IN
• Suitable For Use With: EMT Conduit
• Finish: Zinc Electroplated
• application: For grounding, securing EMT raceways to boxes and enclosures
• Connection: Male NPS Thread
• Standard: UL 514B
• Type: Non-Insulated Throat Straight
• Standard & Approvals: UL 514B/E14815/E14895 Listed, CSA 028507/C22.2 No 18.3 Certified, cUL E14815 Listed, NEMA FB-1, RoHS Complaint
• Insulation: Non-Insulated
