Appleton 570F 1-1/2 Cast Cnd Bdy Cvr

Product Description

The Appleton 570F is a cast conduit body cover designed for use with FM7 Unilet conduit outlet bodies. This part is made from durable cast grayloy-iron and is resistant to corrosion due to its triple-coat finish. The screw-in mounting enables easy installation and secure fitting.

• Hub Size: 1-1/2 inches
• Material: Cast Grayloy-Iron
• Standard: UL 514A and UL 514B

Product Highlights

This cover provides protection and accessibility to the electrical connections within the conduit. Its unique Wedge-Lok clip design allows for effortless removal without causing damage to the conduit.

Product Information

Standard Information

• Manufacturer: Appleton
• Part Number: APP570F

Technical Specifications

• Form: 7
• Type: Blank Clip Cover With Screw
• Color: Gray
• Finish: Triple-Coat (Zinc Electroplate; Chromate And Epoxy Powder Coat)
• Weight: 1.025 lbs
• Special Features: Unique Wedge-Lok clip cover design allows easy removal without damaging the conduit
