Appleton 180-1/2 Conduit Body 1/2 Inch Lb Type

Product Description

The APPLETON 180-1/2 is an LB-type conduit body designed for use in electrical raceway systems where a 90-degree change of direction is required. Sized for 1/2 inch trade size conduit, it measures 4-1/8 inches in length by 1-13/16 inches in width, providing the interior volume needed for conductors to transition direction without exceeding bend radius limits. Licensed electricians install this fitting as part of EMT, rigid metal, or IMC conduit runs in commercial and residential wiring applications. It provides rear and side access through a removable cover plate, simplifying wire pulling on long or complex runs.

This conduit body is suited for use in exposed or concealed indoor conduit systems, junction points, and pull points along a raceway. It is commonly installed in commercial construction, light industrial facilities, and residential service work where conduit must navigate around structural obstacles or transition between directions. The 1/2 inch trade size makes it appropriate for branch circuit and low-voltage control wiring routed through standard conduit systems.

Key Features

• LB-type configuration allows 90-degree conduit direction change with rear access
• 1/2 inch trade size fits standard 1/2 inch EMT, rigid, or IMC conduit
• Body dimensions of 4-1/8 x 1-13/16 inches provide adequate conductor capacity
• Removable cover plate allows access for wire pulling and future maintenance
• Sold in a box quantity, suitable for stocking and multi-unit installations

Compatibility

Designed as an OEM-style fitting compatible with 1/2 inch trade size conduit raceway systems using EMT, rigid metal conduit, or IMC.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements for conduit body fill and conductor bending radius. De-energize all circuits before opening or working within any conduit body. Ensure the removable cover is secured after wire pulling is complete. Do not exceed the conductor fill capacity defined by the NEC for the conduit body volume.

Technical Specifications

• Trade Size: 1/2 inch
• Body Type: LB
• Length: 4-1/8 inches
• Width: 1-13/16 inches
• Package Weight: 54 pounds per 100 units
• UPC: 68785576020

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: 180-1/2
