Apollo Valves 92-104-01 Ball Valve 3/4 Inch Npt

Product Description

The APOLLO VALVES 92-104-01 is a 3/4 inch NPT unibody carbon steel ball valve designed for manual flow control in commercial and industrial piping systems. The unibody construction means the valve body is a single-piece casting, eliminating threaded end connections between body sections and reducing potential leak paths. At 0.76 pounds, this is a compact, lightweight valve suited for tight installations. Licensed plumbers and pipefitters are the primary installers for this type of valve in water, oil, and compatible fluid service lines.

This ball valve is appropriate for residential and light commercial plumbing, hydronic heating systems, and industrial process piping where a reliable shutoff is required at a 3/4 inch NPT connection point. The NPT threaded end connections allow direct installation into standard threaded pipe runs without adapters. The carbon steel body makes it well suited for higher-pressure and higher-temperature applications compared to brass alternatives, where the system media and environment are compatible with carbon steel construction.

Key Features

• Unibody single-piece carbon steel construction minimizes leak paths at body joints
• 3/4 inch NPT threaded connections for direct integration into standard pipe runs
• Compact form factor at 0.76 pounds for use in space-limited installations
• Manual ball valve design provides positive shutoff with a quarter-turn operation

Compatibility

Designed as an OEM-style replacement or new-installation shutoff valve for 3/4 inch NPT threaded piping systems in plumbing, hydronic, and light industrial applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with the applicable local plumbing code and ASME B31 piping standards. Shut off system pressure and drain the line before removing or installing any valve. Apply appropriate thread sealant or PTFE tape to NPT threads, and do not overtighten, as this can crack fittings or damage valve seats. Verify that the system media and operating pressure and temperature are compatible with carbon steel body construction before installation.

Technical Specifications

• Connection Size: 3/4 inches NPT
• Body Material: Carbon Steel
• Body Style: Unibody
• Weight: 0.76 pounds
• UPC: 670750789045

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 92-104-01
