Apollo Valves 30LF-049-01 Class 125 Non-Rising Stem Bronze Gate Valve (2-1/2 inches)

Product Description

Apollo Valves 30LF-049-01 is a lead-free Class 125 bronze gate valve (Model 102S-LF) with a non-rising stem and threaded screw-in bonnet, designed for full-port flow and solder end connections. The valve features a guided solid bronze disc wedge, adjustable graphite stem packing, back seat protection and a malleable iron hand wheel; it is certified for potable water and rated for saturated steam to 125 psi and cold working pressure to 200 psi.

• Lead-free bronze (C89836) construction, NSF/ANSI/CAN 61 and NSF/ANSI 372 certified; ARRA and ANSI third-party compliant.
• Full-port design with guided solid bronze disc wedge, non-rising stem, adjustable graphite stem packing and back seat protection.
• Solder end connections (2 x solder), screw-in bonnet, rated saturated steam 125 psi and cold working pressure 200 psi; assembled in the USA.

Product Highlights

Lead-free full-port bronze gate valve, non-rising stem, solder ends, 2-1/2" size, 125 psi steam / 200 psi cold working pressure.

Product Information

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 30LF-049-01
• Country of Origin: United States

Technical Specifications

• Brand: Apollo Valves
• Manufacturer: Aalberts Integrated Piping Systems Americas, Inc. (Apollo)
• Manufacturer Part Number (MPN): 30LF-049-01
• Model: 102S-LF
• Series: 30 Series (30LF Series)
• Product Type: Gate Valve
• Class Rating: Class 125
• Size: 2-1/2" (DN65)
• End Connection: Soldered sleeve (2 x solder)
• End Style: Solder
• Port: Full port
• Stem Type: Non-rising stem
• Bonnet Type: Threaded (screw-in) bonnet
• Body Material: Bronze (C89836, lead-free)
• Disc/Wedge Material: Solid bronze disc wedge
• Stem Packing: Adjustable graphite stem packing
• Hand Wheel Material: Malleable iron
• Back Seat: Yes (back seat protection)
• Certifications: NSF/ANSI/CAN 61; NSF/ANSI 372; ANSI third-party certified; ARRA compliant
• Saturated Steam Rating: 125 psi
• Cold Working Pressure: 200 psi
• Country of Origin: United States
• Assembly: 100% cast, machined and assembled in the USA
• Weight: 10.76 lb (4.88 kg)
• Dimensions: 5.00 x 4.25 x 11.00 inches (127 x 108 x 279 mm)
• Product Group: Valves
• ETIM Class: EC010163 Gate valve
• UNSPSC: 40141613
• UPC: 670750687075
