Anvil 78101150102 U Support 5-3/8 in Length 1-5/8 in Width

Product Description

The Anvil 78101150102 U Support is a reliable structural component designed for use with various channels. This U support has a length of five and three-eighths inches and a width of one and five-eighths inches. It is compatible with FIG AS 500BTB welded channels and other channels that are one and five-eighths inches wide.

• Manufactured from one-quarter inch thick carbon steel
• All holes are nine-sixteenths inches in diameter, spaced one and seven-eighths inches on center
• Supr-Green powder-coated finish for added durability

Product Highlights

This U support provides stability and strength for construction applications, ensuring a secure fit with compatible channels.

Product Information

Standard Information

• Brand: Anvil
• MPN: 78101150102

Technical Specifications

• Material: Carbon Steel
• Length: 5-3/8 inches
• Width: 1-5/8 inches
• Thickness: 1/4 inch
• Hole Size: 9/16 inch
• Series: FIG AS 613
• Suitable For Use With: FIG AS 500BTB Welded Channel/FIG AS 200/AS 210 and All 1-5/8 inch Wide Channels
