Anvil 310086400 Reducer Coupling 3/4 inches x 1/4 inches

Product Description

The ANVIL 310086400 reducer coupling is a class 150 malleable iron pipe fitting with FNPT connections. Suitable for use in air, natural gas, non-potable water, oil, and steam applications. It conforms to ASME B16.3 standards. Designed for plumbing, HVAC, industrial, and fire protection systems.

• Fitting Connection Type: FNPT
• Pipe Size (Fittings): 3/4" x 1/4"
• Maximum Pressure: 300 psi@150 Degrees F

Product Highlights

This reducer coupling is made of malleable iron and conforms to ASME B16.3 standards.

Product Information

Standard Information

• Brand: ANVIL
• Manufacturer Part Number: 310086400
• Country of Origin: United States

Technical Specifications

• Fitting Schedule/Class: Class 150
• Fitting Connection Type: FNPT x FNPT (Female End x Female End)
• Max. Pressure: 300 psi@150 Degrees F
• Saturated Steam Pressure: 150 psi @ 350 Degrees F
• Basic Fitting Material: Metal
• Basic Fitting Shape: Coupling
• Temp. Range: -20 Degrees to 350 Degrees F
• Specific Fitting Shape: Reducing Coupling
• Pipe Fitting Material: Malleable Iron
• Pipe Size (Fittings): 3/4" x 1/4"
• Standards: UL / FM Approved / ASME B16.3 / ASTM A197 / ASME B1 20.1
• MPN: 310086400
• Finish: Black
• For Use with Pipe Schedule: 40
• Material Type: Black Malleable Iron
• Product Type: Reducing Coupling
• Category Type: Pipe Fittings
• End Connection: NPT
• Brand: Anvil International
