Anvil 310031604 Straight Tee, 4 in. Black Malleable Iron

Product Description

The ANVIL 310031604 is a 4-inch straight tee fitting constructed from black malleable iron. This Class 150 fitting features female NPT threaded connections on all ends. It is designed for use in applications involving air, natural gas, non-potable water, oil, and steam. The fitting conforms to ASME B16.3 and B16.39 standards and is suitable for both commercial and residential use, including fire protection systems.

• Constructed from black malleable iron
• Features 4-inch female NPT threaded connections
• Suitable for use with Schedule 40 pipe

Product Highlights

The ANVIL 310031604 straight tee is ideal for various plumbing applications. It is UL listed and FM approved.

Product Information

Standard Information

• Brand: ANVIL
• Manufacturer Part Number: 310031604
• Country of Origin: USA

Technical Specifications

• Fitting Type: Tee
• Material: Black Malleable Iron
• Size: 4"
• Application: Air, Natural Gas, Non-Potable Water, Oil, Steam, Commercial, Residential, Fire Protection
• Specific Fitting Shape: Tee - Straight (All NPT ends are female and the same size)
• Fitting Schedule/Class: Class 150
• Fitting Connection Type: Female NPT x Female NPT x Female NPT
• Standards: UL Listed / FM Approved / ASME B16.3 / ASME B1 20.1
• Saturated Steam Pressure: 150 psi @ 350 Degrees F
• Operating Temperature: -20 Degrees to 350 Degrees F
• Maximum Operating Pressure: 300 psi @ 150 Degrees F
• Includes Pre-Applied Thread Sealant: No
• Finish: Black
• For Use with Pipe Schedule: 40
• For Use with Flanges/Fittings: Class 150
• Country Of Origin: USA - Domestic
• End Connection: NPT
• Weight (lbs): 11.32
• Additional: Domestic - Made in USA
• Product Type: Tee
• Connection: FNPT
• Pressure Rating: 150 lb
• Type: Straight Pipe Tee
• Domestic: Domestic
• Category: Tee
• Brand: ANVIL
• Body Material: Malleable Iron
• Class: Class 150
• Item: Tee
• Maximum Pressure: 300 psi@150°F
• Mfr. Part Number: 310031604
• Package Quantity: 1
• Pipe Size: 4 in.
• Temperature Range (Deg. F): -20 to 350 deg. F
• Fitting Side A Gender: Female
• Fitting Side A Nominal Pipe Size: 4 in
• Fitting Side A Type: NPT
• Fitting Side B Gender: Female
• Fitting Side B Nominal Pipe Size: 4 in
• Fitting Side B Type: NPT
• Fitting Side C Gender: Female
• Fitting Side C Nominal Pipe Size: 4 in
• Fitting Side C Type: NPT
• Gender: Female
• Threading: NPT
