AMTROL WX255 Well-x-trol Well Tank 81 Gal Replacement MPN

Product Description

The AMTROL WX255 Wx-255 is a well tank designed for domestic water supply. This tank holds eighty-one gallons and features a connection size of one and one-fourth inches. The heavy-duty butyl diaphragm and virgin polypropylene liner enhance the tank's durability and help prevent bacterial growth, making it suitable for plumbing applications.

• Tank Volume: 81 Gallons
• Connection Size: 1-1/4 inches
• 7 Year Limited Warranty

Product Highlights

Reliable performance for well water systems with an efficient design.

Product Information

Standard Information

• Brand: Amtrol
• Model: WX-255

Technical Specifications

• Max Accept. Factor: 0.41
• Precharged PSI: 38 psi
• Max Pressure (PSI): 150
• Height: 56.375 inches
• Diameter: 22 inches
• Max Temp (F): 200 degrees F
• Coating: Blue Enamel
• Shell Material: Steel
• Diaphragm Material: Heavy Duty Butyl
• Liner Material: Virgin Polypropylene
• Application: Plumbing
• Drawdown @ 40/60 PSI: 21.7
• Drawdown @ 30/50 PSI: 25
• Discharge Connection: 1 1/4 inches NPTF
• Includes: Bottom Stand
